Balboa VS100 Model Circuit board. Chip Number VS100R1A. This circuit board is setup for 110V application. OEM part number 56297-02.
SpaGuts P/N: 12-175-6297
NOTE: This circuit board can also be used for 220V application, by removing the 110V Jumper Wire, and running 220V 4-Wire to the circuit board. Doing so will ONLY run the Heater on 220V. The Pump and Ozone circuits will remain on 110V setup.
This circuit board is compatible with the following Balboa Topside Panels: 55563 (VL200 Mini Oval), 52487 (VL200 Mini Oval), 55431 (VL200 Mini Oval, 10ft Cable), 55456 (VL240 Mini Oval, Gray), 55080 (VL240 Mini Oval, White), 54685 (VL260 Mini Oval, Gray), 55081 (VL260 Mini Oval, White), 50063 Panel + 11724 Overlay, 53637 Panel + 11724 Overlay, 53646 Panel + 11724 Overlay, 53999 Panel + 11724 Overlay, 50063 Panel + 11746 Overlay, 53637 Panel + 11746 Overlay, 53646 Panel + 11746 Overlay, 53999 Panel + 11746 Overlay, 53636 Panel + 11745 Overlay, 53644 Panel + 11745 Overlay, 53280 Panel + 11219 Overlay, 54252 Panel + 11219 Overlay, 55472 Panel + 11219 Overlay, 53280 Panel + 11852 Overlay, 54252 Panel + 11852 Overlay, 55472 Panel + 11852 Overlay, 54135 (VL401 Lite Duplex), 54665 (VL401 Lite Duplex), 52424 Panel + 10839 Overlay, 52424 Panel + 11885 Overlay, 54105 (VL403 Lite Duplex), 54664 (VL403 Lite Duplex), 54130 Panel + 10753 Overlay, 54130 Panel + 11884 Overlay, 50217 (VL406T Duplex), 55413 Panel + 12438 Overlay, 50195 Panel + 12438 Overlay, 50210 Panel + 12438 Overlay, 50222 Panel + 12438 Overlay, 55350 (VL406U Duplex), 53272 (VL406U Duplex, 10ft Cable), 55417 Panel + 11947 Overly, 53271 + 11947 Overlay
This circuit board is also a replacement option for the following part numbers: 54821-04 (110V Kit with GFCI), 56298-03 (220V System), 54805 (220V Kit), 10-175-4805 (220V System), 54808 (110V Kit), 56473-03 (110V System), 54825 (110V System), 56296-03 (110V System), G4111 (110V System), 10-200-4821 (110V Kit), 10-175-4821 (110V System), 33-56297-K
This item comes with a 1-year limited warranty.
When selecting your spa circuit board, it’s critical that you go by part numbers and NOT just by appearances. The part number on a spa circuit board can be found on a white sticker located directly on the circuit board (The ID label may be located on the board relays or on the transformer). Buy based on this part number. Do NOT purchase a hot tub circuit board just because it looks the same OR have the same Model Number as the one you’re replacing. Spa circuit boards can look identical, but be programmed differently to work with different spa controllers and topside panels. NOTE that most circuit boards need to be configured in the field to work with the existing spa components and power ratings, and a licensed professional is recommended for installation and configurations. If this circuit board is being used as an optional replacement for the original circuit board, please follow the new circuit board wiring diagram for proper installation and configuration setup. Replacement spa circuit boards are shipped in clear sealed bags with Yellow Warning Label. Verify through the clear sealed bag that the correct circuit board was received prior to opening the bag. Sealed bags that are opened voids the return policy for spa circuit boards.
