Balboa Control System, EL8000M3, 5.5KW, No Topside, No Cords, 55064 (SEE REPLACEMENTS BELOW)

Out of stock
Discontinued
SKU
11-175-5064
$0.00

Balboa Control System, Model EL8000M3, 5.5KW 220V Heater. Topside Panel and Cords are Sold Separately. This system will operate up to 3 pumps, No Blower. Normally used for Swim Spa Application. OEM part number 55064-04.

THIS ITEM IS NO LONGER AVAILABLE. IT HAS BECOME OBSOLETED BY THE MANUFACTURER. SEE BELOW ALTERNATIVE REPLACEMENT OPTIONS THAT MAY REQUIRE RETROFITTING:

1) Link to see the 405A SpaGuts brand SGBP7 Spa Controller Kit w/ SGTP600 Topside, 5.5KW

2) Link to see the 407A SpaGuts brand SGBP7 Spa Controller Kit w/ TP700 Topside, 5.5KW

3) Link to see the 11-200-2005 SpaGuts SGBP2000G1 Spa Controller Kit w/ Topside TP600, 5.5KW HTR

4) Link to see the 11-200-2025 SpaGuts SGBP2000G1 Spa Controller Kit w/Topside TP700, 5.5KW HTR

5) Link to see the 11-200-2035 SpaGuts SGBP2000G1 Spa Controller Kit w/ Topside SpaTouch3, 5.5KW HTR

This control system operates on 220V 60Hz 4-Wire (Line 1, Line 2, Neutral and Ground). The EL8000M3 control system is equipped with M7 technology which allows the heater to be mounted either on the suction or discharge side of the pump.

SpaGuts P/N: 11-175-5064

Features:

  • Pump 1 circuit, two speed, 110/220V, 12A Max
  • Pump 2 circuit, Single or Dual Speed, 110/220V, 12A Max
  • Pump 3 circuit or Blower, 1-speed, 110/220V, 12A Max
  • Ozone circuit, 110/220V, 1A Max
  • Audio/Video circuit, 110V, 2A Max (Constant Circuit)
  • 12V Light circuit, OR 110V Fiber Optics Light circuit (2A Max)
  • 5.5KW, 240V Flo-Thru Incoloy High Flow heater with M7 technology
  • Stainless steel heater housing
  • No Pressure Switch. Heater can be installed on suction or
    discharge side of pump
  • UL and ETL listed for
    your safety
  • Freeze protection
  • High-limit protection
  • Filtration mode
  • Economy Mode
  • Persistent Memory
  • Real Time Clock
  • Pair of 2.0 inch Heater Tailpieces with O-Ring Gaskets
  • 1-Year Limited Warranty

This control system is compatible with the following Balboa topside panels: 54589-03 ML900, 53605 M7 Sensors, 30270-2 Transformer, 52765 Auxiliary Topside Panel

Controller Dimensions (Approx): 12.25 inch L x 15.02 inch H x 3.56 inch W

Heater Dimensions (Approx): 15 inch L x 2.0 inch Diameter

This control system is also a replacement option for the following part numbers:
